Mođun điều khiển dùng cho seri 9000 TOA AN-001T
-TOA AN-001T là một plug-in module của 2 kênh tiếng ồn xung quanh phát hiện được thiết kế để sử dụng với các dòng ampli TOA 9000.
-AN-001T sẽ tự động điều chỉnh âm lượng đầu ra để đáp ứng với sự thay đổi của mức độ tiếng ồn xung quanh.
-AN-001T có thể xử lý các tín hiệu đầu vào từ cấp microphone (-60 dB) đến mức dòng (-10dB) bằng cách kiểm soát đạt được trong 9 bước.
-Phantom điện (24V) có thể được cung cấp để sử dụng condenser microphone.
Đặc tính kỹ thuật
| Power Source | +24VDC, -24VDC, +6 VDC |
| Current Consumption | 20 mA (at +24 VDC), 20 mA (at -24 V DC), 60 mA (at +6 VDC) |
| Input | Sensor input (Ambient noise sensor microphone input): 2 channels, |
| 3 kΩ (when the phantom power is ON)/10 kΩ (when the phantom power is OFF) | |
| electronically-balanced, removable terminal block (3 pins) | |
| Input Sensitivity | -60, -54, -48, -42, -36, -30, -24, -18, -10 dB* (selectable) |
| Phantom Power | +24 V DC |
| A/D Converter | 24 bit ADC |
| Sampling Frequency | 48 kHz |
| Ambient Noise Control Function | Sensor input reference level adjustment function |
| Maximum output signal level control: -15 to 0 dB | |
| Minimum output signal level control: -18 to -3 dB | |
| Sample time setting: 10 s, 15 s, 20 s, 30 s, 1 min, 2 min, 3 min, 5 min | |
| Gain ratio setting (Ambient noise: Output signal level): | |
| Operating Temperature | -10℃ to +40℃ |
| Finish | Panel: Aluminum, hair-line |
| Dimensions | 35 x 78 x 91.5mm |
| Weight | 82 g |
| Accessory | Removable terminal plug (3 pins) …2, Module mounting screw …2 |
| Option | Ceiling mount microphone: AN-9001 |
-Sản xuất tại Trung Quốc.
-Bảo hành: 12 tháng.
