Công tắc hẹn giờ dạng cơ THEBEN SYN 161 d
- Analogue time switch
- 1 channel
- Daily program
- Without power reserve
- 96 switching segments
- Synchronised with mains
- Shortest switching time: 15 minutes
- Clock hands for time display and in addition 12/24 hour recognition
- Simple summer/winter time correction
- Time can be changed clockwise or anti-clockwise
- DuoFix spring terminals
- For 2 conductors each
- Wire or strand (with or without wire end sleeve)
- Wire diameter: 0.5 - 2.5 mm
- Button for releasing plug-in connection
- Switching preselection
- Manual switch with 3 positions: Continuous ON/AUTO/continuous OFF
- Switching status display
Specifications
Operating voltage | 230 V AC |
Frequency | 50 Hz |
Number of channels | 1 |
Program | Daily program |
Width | 3 modules |
Installation type | DIN rail |
Type of connection | DuoFix spring terminals |
Drive | Synchronous motor |
Program | Daily program |
Switching capacity at 250 V AC, cos φ = 1 | 16 A |
Switching capacity at 250 V AC, cos φ = 0,6 | 4:00 AM |
Incandescent/halogen lamp load | 1100 W |
Shortest switching times | 15 min |
Programmable every | 15 min |
Time accuracy | Synchronised with mains |
Type of contact | Changeover contact |
Switching output | Potential-free and phase-independent |
Number of switching segments | 96 |
Stand-by consumption | 1 VA |
Test approval | VDE |
Housing and insulation material | High-temperature resistant, self-extinguishing thermoplastic |
Type of protection | IP 20 |
Protection class | II as per EN 60 730-1 |
Ambient temperature | -20 C +55 C |
- Hãng sản xuất THEBEN của Đức.
- Bảo hành: 12 th ng.
