Bộ lưu điện UPS APC SMC1500IC
- Công suất: 900Watts / 1.5kVA.
- Công nghệ: Line Interactive.
- Nguồn điện ngõ ra: 220, 240VAC.
- Tần số ngõ ra: 50/60Hz +/- 3 Hz.
- Nguồn điện ngõ vào: 220, 240VAC.
- Tần số ngõ vào: 50/60 Hz +/- 3 Hz (auto sensing).
- Giao tiếp cổng: USB.
- Dạng sóng: Sóng sine.
- Ắc quy (Battery Volt-Amp-Hour Capacity): 288 (VAH).
- Thời gian chuyển mạch: 6ms (typical), 10ms (maximum).
- Thời gian sạc: 3 giờ.
- Pin thay thế: RBC6.
- Kết nối ngõ ra: (8) IEC 320 C13.
- Thích hợp sử dụng cho các thiết bị như: Máy vi tính, máy in, Wifi, máy chấm công, máy tính tiền, tổng đài điện thoại, máy Fax, cửa từ, thiết bị viễn thông, thiết bị mạng, camera,…
- Kích thước: 219 x 171 x 439mm.
- Trọng lượng: 20.1kg.
Đặc tính kỹ thuật
| Model | SMC1500IC |
| Output | |
| Max Configurable Power (Watts) | 900Watts / 1.5kVA |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Output Voltages | 220, 240 |
| Topology | Line Interactive |
| Waveform type | Sine wave |
| Transfer Time | 6ms typical : 10ms maximum |
| Input | |
| Input frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input voltage range for main operations | 180 - 287V |
| Input voltage adjustable range for mains operation | 170 - 300V |
| Other Input Voltages | 220, 240 |
| Batteries & Runtime | |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time | 3hour(s) |
| Expected Battery Life (years) | 3-5 |
| Replacement Battery | RBC6 |
| RBC Quantity | 1 |
| Battery Charge Power (Watts) | 96Watts |
| Battery Volt-Amp-Hour Capacity | 288 |
| Communications & Management | |
| Interface Port(s) | USB |
| Control panel | Multi-function LCD status and control console |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Surge Protection and Filtering | |
| Surge energy rating | 459Joules |
| Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Physical | |
| Maximum Height | 219MM, 21.9CM |
| Maximum Width | 171MM, 17.1CM |
| Maximum Depth | 439MM, 43.9CM |
| Net Weight | 20.1KG |
| Shipping weight | 22.64KG |
| Shipping Height | 330MM, 33.0CM |
| Shipping Width | 330MM, 33.0CM |
| Color | Black |
| Master Carton Units | 1.0 |
| Units per Pallet | 18 |
| Environmental | |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95 % |
| Operating Elevation | 0-3000meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95 % |
| Storage Elevation | 0-15000meters |
| Audible noise at 1 meter from surface of unit | 45.0dBA |
| Online thermal dissipation | 135.0BTU/hr |
- Sản xuất tại Trung Quốc hoặc Philippin.
- Bảo hành: 12 tháng.
